Pixel Pitch: ≤3.91mm
Pixel Density: ≥65,536 dots/m²
Module Size: 250mm×250mm
Module Resolution: ≥64*64
Brightness (cd/m²): 5200 adjustable
Viewing Angle (Horizontal/Vertical): ≥160°
Refresh Rate: 1920/3840Hz
Frame Rate: 60Hz
Module Power Consumption: ≤47W
Peak Power Consumption: ≤752W
Lifespan: ≥200,000 hours
Product parameters
| Parameter | S3.91 |
| Specificaations(mm) | S3.91BQ-16S-6464 |
| Pixel Pitch(mm) | 3.91 |
| Display resolution（dots） | 64×64＝4096 |
| Physical Density (Pixels/ ㎡) | 65536 |
| LED Encapsulation | |
| Pixel specifications | 1R1G1B |
| Module Size(mm) | L250×H250×T15 |
| Module Weigth(g/pcs) | 600 |
| Driving mode | 1/16SConstant current drive |
| Module Consumption(W) | ≤47 |
| Max. Power Consumption(w/㎡) | ≤752 |
| Refresh Frequency (Hz) | 1920/3840 |
| Brightness(cd/㎡) | 5200(adjustable) |
| Optimum Viewing Angle | H:160° V:160° |
| Gray Scale (bit) | 12月16日 |
| Frame Frequency (Hz) | ≥60 |
| Module Working Voltage(V) | 4.8-5.2 |
| Operating Temperature/Humidity（C/RH） | -10°C-+40°C10%RH-90%RH |
