Pixel Pitch: ≤10mm
Pixel Density: ≥10,000 dots/m²
Module Size: 320mm×160mm
Module Resolution: ≥32*16
Brightness (cd/m²): 6700 adjustable
Viewing Angle (Horizontal/Vertical): ≥160°
Refresh Rate: 1920/3840Hz
Frame Rate: 60Hz
Module Power Consumption: ≤46W
Peak Power Consumption: ≤900W
Lifespan: ≥200,000 hours
Product parameters
| Parameter | S10 | |
| Specificaations(mm) | S10BG-2S-3216 | S10BG-2S-3216 |
| Pixel Pitch(mm) | 10 | 10 |
| Display resolution（dots） | 32×16＝512 | 32×16＝512 |
| Physical Density (Pixels/ ㎡) | 10000 | |
| LED Encapsulation | ||
| Pixel specifications | 1R1G1B | |
| Module Size(mm) | L320×H160×T15 | |
| Module Weigth(g/pcs) | 430 | 400 |
| Driving mode | 1/2SConstant current drive | 1/4SConstant current drive |
| Module Consumption(W) | ≤46 | ≤28 |
| Max. Power Consumption(w/㎡) | ≤900 | ≤547 |
| Refresh Frequency (Hz) | 1920/3840 | |
| Brightness(cd/㎡) | 6700(adjustable) | 4500(adjustable) |
| Optimum Viewing Angle | H:160° V:160° | |
| Gray Scale (bit) | 12月16日 | |
| Frame Frequency (Hz) | ≥60 | |
| Module Working Voltage(V) | 4.8-5.2 | |
| Operating Temperature/Humidity（C/RH） | -10°C-+40°C10%RH-90%RH | |
