Pixel Pitch: ≤1.5625mm
Pixel Density: ≥410,914 dots/m²
Cabinet Size: 660*337.5*45.6mm
Cabinet Resolution: ≥384*216
Brightness (cd/m²): 450-600 adjustable
Viewing Angle (Horizontal/Vertical): 160±10° / 160±10°
Refresh Rate: 3840Hz
Frame Rate: 60Hz
Average Power Consumption: 133-200W
Peak Power Consumption: ≤400W
Lifespan: ≥100,000 hours
Product parameters
| Parameter | Mini COB 0.9375 | Mini COB1.25 | Mini COB1.5625 |
| Pixel Pitch(mm) | 0.9375 | 1.25 | 1.5625 |
| Pixel packaging | 1R1G1BFlip chip | ||
| Circuit scheme | Co-yin | Gongyang | ||
| Cabinet Size<W×H×D>(mm) | 660×337.5×45.6 | ||
| Cabinet Weight(kg/pcs) | 6.8 | ||
| Panel Resolution(pixels) | 640×360 | 480×270 | 384×216 |
| Physical Density（Pixel/㎡） | 1137777 | 640000 | 410914 |
| Brightness(cd/㎡) | 450~600（adjustable) | ||
| Refresh Rate(Hz) | 3840 | ||
| Frame Frequency(Hz) | ≥60 | ||
| Max.Power Consumption（w/㎡） | ≤523.5 | ≤392 | ≤400 |
| AVE. Power Consumption(w/㎡) | 174~262 | 130~196 | 133~200 |
| Module Working Voltage(V) | DC2.8/3.8 | DC2.8/3.8 | DC3.8 |
| Input Voltage | AC：110V~240V、50~60Hz | ||
| Viewing Angle(°) | 160±10°/160±10° | ||
| Gray Scale(bit） | 16 | ||
| Highest contrast | 10000:1 | ||
| Protection class | 背⾯：IP41 正⾯：IP54 | ||
| Typical Lifespan(Hr) | ≥100000 | ||
| Operating Temperature/Humidity（C/RH） | -10°C-+40°C10%/RH- 90%RH | ||
