Pixel pitch: ≤1.53mm
Pixel density: ≥422,753 dots/㎡
Module size: 320mm × 160mm
Module resolution: ≥208 × 104
Brightness (cd/㎡): 500, adjustable
Horizontal/vertical viewing angle: ≥160°
Refresh rate: ≥3840Hz
Frame rate: 60Hz
Module power consumption: ≤17W
Peak power consumption: ≤331W
Lifespan: ≥200,000 hours
Product Parameters
| Parameter | P1.53 |
| Specificaations(mm) | P1.53BI-52S-208104 |
| Pixel Pitch(mm) | 1.53 |
| Display resolution（dots） | 208×104＝21632 |
| Physical Density (Pixels/ ㎡) | 422753 |
| LED Encapsulation | SMD1212 |
| Pixel specifications | 1R1G1B |
| Module Size(mm) | L320×H160×T15 |
| Module Weigth(g/pcs) | 495 |
| Driving mode | 1/52SConstant current drive |
| Module Consumption(W) | ≤17 |
| Max. Power Consumption(w/㎡) | ≤331 |
| Refresh Frequency (Hz) | 3840 |
| Brightness(cd/㎡) | ≥500(adjustable) |
| Optimum Viewing Angle | H:160° V:160° |
| Gray Scale (bit) | 12/16 |
| Frame Frequency (Hz) | ≥60 |
| Module Working Voltage(V) | 4.8-5.2 |
| Operating Temperature/Humidity（C/RH） | -10°C-+40°C10%RH-90%RH |
Introduction
